Detecting if a remote connection is mobile in Apache

As many of you have heard, Google is requiring that sites pass their ‘mobile usability’ test if they want to show up in mobile search rankings. After April 22nd, Google will start rolling out changes to their listings, and those who don’t pass the test stand to lose a lot of traffic.

I was pretty concerned until I realized that our biggest problem is all of the small menus around our content. That stuff works fine on a desktop, but fat fingers (compared to a mouse pointer) can’t discern between tightly spaced links.

So… Why not just make all of the menus disappear for mobile users?

It seemed like the easiest way would be to create an environment variable from within Apache. This would let me either use Server Side Includes (SSI) or make programmatic changes in scripts.

The trick, of course, was figuring out which visitors were mobile and which ones weren’t. Setting an environment variable wouldn’t be of much use if I was identifying the wrong visitors.

I ended up finding a great Apache regular expression at Although the regular expression had what I needed, they were using it to rewrite mobile visitors to another URL. I just wanted to set a variable, not redirect people. Here’s what I came up with instead.

RewriteEngine On
RewriteCond %{HTTP_USER_AGENT} (android|bb\d+|meego).+mobile|avantgo|bada\/|blackberry|blazer|compal|elaine|fennec|hiptop|iemobile|ip(hone|od)|iris|kindle|lge\ |maemo|midp|mmp|mobile.+firefox|netfront|opera\ m(ob|in)i|palm(\ os)?|phone|p(ixi|re)\/|plucker|pocket|psp|series(4|6)0|symbian|treo|up\.(browser|link)|vodafone|wap|windows\ ce|xda|xiino [NC,OR]
RewriteCond %{HTTP_USER_AGENT} ^(1207|6310|6590|3gso|4thp|50[1-6]i|770s|802s|a\ wa|abac|ac(er|oo|s\-)|ai(ko|rn)|al(av|ca|co)|amoi|an(ex|ny|yw)|aptu|ar(ch|go)|as(te|us)|attw|au(di|\-m|r\ |s\ )|avan|be(ck|ll|nq)|bi(lb|rd)|bl(ac|az)|br(e|v)w|bumb|bw\-(n|u)|c55\/|capi|ccwa|cdm\-|cell|chtm|cldc|cmd\-|co(mp|nd)|craw|da(it|ll|ng)|dbte|dc\-s|devi|dica|dmob|do(c|p)o|ds(12|\-d)|el(49|ai)|em(l2|ul)|er(ic|k0)|esl8|ez([4-7]0|os|wa|ze)|fetc|fly(\-|_)|g1\ u|g560|gene|gf\-5|g\-mo|go(\.w|od)|gr(ad|un)|haie|hcit|hd\-(m|p|t)|hei\-|hi(pt|ta)|hp(\ i|ip)|hs\-c|ht(c(\-|\ |_|a|g|p|s|t)|tp)|hu(aw|tc)|i\-(20|go|ma)|i230|iac(\ |\-|\/)|ibro|idea|ig01|ikom|im1k|inno|ipaq|iris|ja(t|v)a|jbro|jemu|jigs|kddi|keji|kgt(\ |\/)|klon|kpt\ |kwc\-|kyo(c|k)|le(no|xi)|lg(\ g|\/(k|l|u)|50|54|\-[a-w])|libw|lynx|m1\-w|m3ga|m50\/|ma(te|ui|xo)|mc(01|21|ca)|m\-cr|me(rc|ri)|mi(o8|oa|ts)|mmef|mo(01|02|bi|de|do|t(\-|\ |o|v)|zz)|mt(50|p1|v\ )|mwbp|mywa|n10[0-2]|n20[2-3]|n30(0|2)|n50(0|2|5)|n7(0(0|1)|10)|ne((c|m)\-|on|tf|wf|wg|wt)|nok(6|i)|nzph|o2im|op(ti|wv)|oran|owg1|p800|pan(a|d|t)|pdxg|pg(13|\-([1-8]|c))|phil|pire|pl(ay|uc)|pn\-2|po(ck|rt|se)|prox|psio|pt\-g|qa\-a|qc(07|12|21|32|60|\-[2-7]|i\-)|qtek|r380|r600|raks|rim9|ro(ve|zo)|s55\/|sa(ge|ma|mm|ms|ny|va)|sc(01|h\-|oo|p\-)|sdk\/|se(c(\-|0|1)|47|mc|nd|ri)|sgh\-|shar|sie(\-|m)|sk\-0|sl(45|id)|sm(al|ar|b3|it|t5)|so(ft|ny)|sp(01|h\-|v\-|v\ )|sy(01|mb)|t2(18|50)|t6(00|10|18)|ta(gt|lk)|tcl\-|tdg\-|tel(i|m)|tim\-|t\-mo|to(pl|sh)|ts(70|m\-|m3|m5)|tx\-9|up(\.b|g1|si)|utst|v400|v750|veri|vi(rg|te)|vk(40|5[0-3]|\-v)|vm40|voda|vulc|vx(52|53|60|61|70|80|81|83|85|98)|w3c(\-|\ )|webc|whit|wi(g\ |nc|nw)|wmlb|wonu|x700|yas\-|your|zeto|zte\-) [NC]
RewriteRule ^ - [E=MOBILE_TMP:1]

As you can see, the first three lines came from The last two lines set the environment variable in a two-step process.

The mod_rewrite line that starts with RewriteRule sets a variable named MOBILE_TMP to ‘1’ if any of the regular expressions match. Unfortunately, Apache won’t pass that environment variable on to CGI scripts. mod_header, however, can pass variables that it sets.

The last line uses this feature in mod_header to set another variable named HTTP_MOBILEUSER to the value of MOBILE_TMP if MOBILE_TMP is set. Note that the variable is called HTTP_MOBILEUSER, not MOBILEUSER. The RequestHeader directive will prepend the string ‘HTTP_’ to whatever environment variable you pick.

Most of our pages at use SSI, so it’s very easy for me to tell the system to exclude blocks of code for mobile users now. Here’s a sample SSI snippet that only includes the files if it’s a mobile user. If not, they’re excluded.

<!--#if expr="${HTTP_MOBILEUSER} != /1/" -->
   <!--#include virtual="/include/root-top.html"-->
   <!--#include virtual="/include/vertical-spacer8.html"-->
   <!--#include virtual="/include/root-left.html"-->
<!--#endif -->

Another example sets the background color of a page to green for mobile users, but white for desktop users:

<!--#if expr="${HTTP_MOBILEUSER} != /1/" -->
<body bgcolor="#FFFFFF" vlink="#668F66" link="#000000">
<!--#else -->
<body bgcolor="#004400" vlink="#668F66" link="#000000">
<!--#endif -->

Of course, it would be ideal to use CSS for these, but when you have 800,000 legacy pages dating back nearly twenty years this is much simpler!

Sometimes our Perl scripts also had stylistic changes for mobile users too. In this case, we choose a different image for mobile visitors:

if ($ENV{'HTTP_MOBILEUSER'} == 1) {
   $imagedir = "/mnt/WWW/";
} else {
   $imagedir = "/mnt/WWW/";


  $imagedir = sprintf(qq(/mnt/WWW/,
     ($ENV{'HTTP_MOBILEUSER'} == 1) ? "mobile" : "desktop"

Making these changes ended up being easier than I thought, and for that I’m grateful. There are still some tweaks to make to, and we still need to add some mobile navigation options to our pages. But for now we’ll continue to show up in the search rankings, our traffic won’t disappear, and most importantly, people will be able to use our pages on mobile devices.
